Kaufman Trailers
62000 GVWR Heavy Equipment Flatbed Trailer – 30 ft.
$24,990.00 Factory Direct
Price Shown Does Not Include FET
Trailer Description
Kaufman Trailers tri-axle airbrake 62000 GVWR Heavy Equipment Flatbed Trailer is an industry leader in value. Construction begins with one piece 14 in. at 26 lb./ft. high tensile main beams. We cold form the tongue in a hydraulic press for a gradual transition and use pierced crossmember construction. Fleetcraft or Power Products 22.5K airbrake oil bath axles ride on a Hutchens long life suspension. A Haldex ABS braking system, spring brakes on all axles, oak flooring, Sealco modular wiring harness, and a tool tray with a lockable lid make this a fully equipped tri-axle 62000 GVWR Heavy Equipment Flatbed Trailer. Optional hydraulic ramps make this flatbed trailer perfect for paving equipment.
TRAILER IS SHOWN WITH OPTIONAL HYDRAULIC PAVER RAMPS.
VIEW OUR ENTIRE LINE OF FLATBED TRAILERS
CALL CUSTOMER SERVICE WITH QUESTIONS: 866-455-7444
Specifications| G.V.W.R. | 62,000 lb. 11,440 lb. empty wt., Capacity 50,560 lb. |
| Electrical | DOT approved lights, connectors, and sealed wiring harness |
| Frame | 14 in. Pierced i-beam, 26 ppf. with 4 in. channel crossmembers, 16 in. o.c. |
| Dovetail | 5 ft. Oak |
| Upper Deck | N/A |
| Side Rail | 8 in. channel |
| Tongue | Cold formed |
| Tires | 215/75 R17.5 LRH (4,540 lb.) |
| Floors | Oak |
| Coupler | Adjustable pintle eye |
| Safety Chains | Heavy duty safety chains |
| Ramps | 72in. x 28in. Heavy duty wood lined, Swing-up with spring assist |
| Tie Downs | D-rings |
| Deck Length | 30 ft. (25 ft. flat + 5 ft. dove) |
| Deck Height | 35 in. With side steps standard |
| Deck Width | Maximum 102 in. |
| Fenders | N/A |
| Lower Deck | N/A |
| Brakes | All wheel air brake with spring lock each wheel (ABS) |
| Tailgate | N/A |
| Wheels | Heavy duty dual 17.5 in. wheels |
| Jack | 2-25,000 lb. Dual speed jacks |
| Axles | 3-22,500 Fleetcraft or Power Products oil bath axles |
| Suspension | Hutchens slipper |
| Toolbox | Lockable lid on tongue |
| Finish | Primed, 2 coats of automotive grade enamel |
| Spare tire and rim | $400.00 |
| 9K Winch | $1,250.00 |
| No dovetail or ramps (Straight deck) *Special deposit required | $-99.00 |
| 5 ft. Self-cleaning (cleated angle iron) dove | $500.00 |
| Air Lift Front Axle | $4,000.00 |
| Self-contained hydraulic ramps, with sizes up to 34.5 in. x 96 in. for wood lined. And 33 in. x 96 in. for self-cleaning (cleated angle iron) | $3,400.00 |
| Product Number | Length | Price | Additional Info |
|---|---|---|---|
| FAP-3/22.5K-30 | 30 ft. | $24,990.00 | Tongue: Cold Formed Frame: 14 in. x 26 ppf. Pierced I-beam Crosspiece: 4 in. Channel Centers: 16 in. Side Rail: 8 in. Channel Ramp Runners: 8 in. Channel |
| FAP-3/22.5K-35 | 35 ft. | $26,490.00 | Tongue: Cold Formed Frame: 14 in. x 26 ppf. Pierced I-beam, with torque tube Crosspiece: 4 in. Channel Centers: 16 in. Side Rail: 8 in. Channel Ramp Runners: 8 in. Channel |
