Kaufman Trailers
17000 GVWR Deluxe Wood Floor Skid Steer Trailer – 20 ft.
$7,790.00 Factory Direct
Our 17000 GVWR Deluxe Wood Floor Skid Steer Trailer is built with a 7 in. x 4 in. x 3/8 in. angle iron frame, 6″ channel full length wrap around tongue, a 12,000 lb. drop foot jack and a super duty 3-bolt cast iron adjustable coupler. The running gear upgrades to 8,000 lb. four wheel brake axles with heavy duty slipper spring suspension and 215/75 R17.5 load range H tires. A tool box with a lockable lid, stake pockets with rub rail, and heavy gauge diamond plate fenders are all included. We beef up the ramps with 4 in. channel ramp runners and include spring assist. A US made sealed modular wiring harness and lifetime LED lighting ensure trouble free lighting for years to come.
Contact our customer service team today to find out how easy it is to have a 17000 GVWR Deluxe Wood Floor Skid Steer Trailer delivered direct to your location.
TRAILER IS SHOWN IN OPTIONAL YELLOW.
VIEW OUR ENTIRE LINE OF EQUIPMENT TRAILERS
CALL CUSTOMER SERVICE WITH QUESTIONS: 866-455-7444
Specifications| G.V.W.R. | 17,000 GVWR |
| Electrical | Sealed modular wiring harness with LED lights |
| Frame | 4x7x3/8 angle frame, with 3 in channel crossmembers |
| Dovetail | N/A |
| Upper Deck | N/A |
| Side Rail | N/A |
| Tongue | 6 in. Channel wrap around |
| Tires | 215/75 R17.5 |
| Floors | 2 in. Treated Wood |
| Coupler | Super duty 3 bolt cast iron 2 5/16 adjustable coupler |
| Safety Chains | Heavy duty safety chains |
| Ramps | 60 in. x 20 in. heavy duty flip up ramps - 4 in. channel ramp runners - with spring assist |
| Tie Downs | Stake pockets and rubrail |
| Deck Length | 20 ft. |
| Deck Height | 21 in. |
| Deck Width | 82 in. between fenders |
| Fenders | Diamond plate fenders |
| Lower Deck | N/A |
| Brakes | All wheel electric brakes |
| Tailgate | N/A |
| Wheels | Heavy duty steel wheels |
| Jack | 12,000 lb. Drop foot jack |
| Axles | 2-8,000 lb. e-z lube axles |
| Suspension | Slipper springs |
| Toolbox | Chain box with lockable toolbox |
| Finish | Primed, 2 coats of automotive grade enamel, pin striped |
| Spare tire and rim (17.5) | $400.00 |
| Adjustable 2-5/16 in. ball and pintle ring | $80.00 |
| Fork holders (requires measurement information) | $200.00 |
| 5 ft. Heavy duty spring assist split gate (Capacity 12,500 lb. piece of equipment) | $600.00 |
| Product Number | Length | Price | Additional Info |
|---|---|---|---|
| FSW-8K-16D | 16 ft. | $7,770.00 | Frame: 4x7x3/8 in. Angle Tongue: 6 in. Channel Crosspiece: 3 in. Channel Centers: approx. 16 in. |
| FSW-8K-18D | 18 ft. | $7,780.00 | Frame: 4x7x3/8 in. Angle Tongue: 6 in. Channel Crosspiece: 3 in. Channel Centers: approx. 16 in. |
| FSW-8K-20D | 20 ft. | $7,790.00 | Frame: 4x7x3/8 in. Angle Tongue: 6 in. Channel Crosspiece: 3 in. Channel Centers: approx. 16 in. |
